{"id":9140836630765,"title":"YY3568 Open-Source Developer Kit Rockchip RK3568 Soc Support Android11.0, Debian10.0 and OpenHarmony OS, 64-bit AI Mainboard for Face Recognition Prototyping (Metal Kit with WiFi 8GB RAM)","handle":"yy3568-open-source-developer-kit-rockchip-rk3568-soc-support-android11-0-debian10-0-and-openharmony-os-64-bit-ai-mainboard-for-face-recognition-prototyping-metal-kit-with-wifi-8gb-ram","description":"\u003ch3\u003eYY3568 Open-Source Developer Kit Rockchip RK3568 Soc Support Android11.0, Debian10.0 and OpenHarmony OS, 64-bit AI Mainboard for Face Recognition Prototyping (Metal Kit with WiFi 8GB RAM)\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003e-Specification- Soc: Rockchip RK3568 CPU: Quad-core 64-bit Cortex-A55, 22nm lithography process, frequency up to 2.0GHz GPU: ARM G52 2EE Supports OpenGL ES 1.1\/2.0\/3.2，OpenCL 2.0，Vulkan 1.1, Embedded high-performance 2D acceleration hardware\" NPU: 0.8Tops@INT8,integrated high-performance AI accelerator RKNN NPU Supports 8M ISP, supports HDR RAM: 2GB LPDDR4 Storage: 16GB eMMC -OS\/Software- OS Support Android11, Debian10,OpenHarmony system Power Supply: 1 x 12~19V DC Power Input Jack (5.5\/2.1 mm) -Others- Size:120mm x 88mm x 19mm Weight: 113g Operating Temperature: -10℃～60℃\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eKind Reminder: There are various variants. For shipping list, you can refer to the last description of title(content in brackets) or you can contact us by click\"WayPonDev\" if you are not sure.\u003c\/li\u003e\r\n \u003cli\u003e[Android and Linux OS Support] YY3568 is compatible with Android 11.0, debian 10.0 and OpenHarmony OS,which gives users options and flexibility when developing their projects\u003c\/li\u003e\r\n \u003cli\u003e[Customizable Hardware and Software]The core board conbined with carrier board design that help YY3568 developer kit provides users with the ability to customize hardware functions. And we can also offer cross-soc OS porting, BSP kernel trimming, as well as driver development. This allows for a tailored experience and more effective development\u003c\/li\u003e\r\n \u003cli\u003e[Easy to Use Add-ons and Accessories] WayPonDEV team develop a variety of compatible accessories including 7-inch MIPI Touch Screen, 11.6-inch eDP touch screen, cameras, 4GB LTE module and acrylic case as well as metal shell etc. This helps greatly reduce the cycle from product selection, R\u0026amp;D project establishment, small batch trial production to mass production\u003c\/li\u003e\r\n \u003cli\u003e[Fast Network Communication] - With onboard dual adaptive Gigabit Ethernet RJ45, 2.4GHz\/5GHz dual-band WiFi 5 (WiFi5, 802.11a\/b\/g\/n\/ac\/ protocol), Bluetooth 5.0, and 4G LTE expansion supported, YY3568 ensures faster-rate, larger-capacity, and lower-latency network communication\u003c\/li\u003e\r\n \u003cli\u003e[Rich Extensible Interfaces]Equipped with interfaces such as CAN, M.2 PCIE3.0, USB3.0, I2C, SPDIF, UARTx5,UART Debug,4x ADC,30 GPIO, 2x MULTI_PHY, MIPI-DSI,CSI, MIC and 12~19V DC Power Input Jack (5.5\/2.1 mm),it can be directly used in various intelligent products to facilitate the completion of products\u003c\/li\u003e\r\n \u003cli\u003e[Wiki] http(s):\/\/wiki.youyeetoo.com\/YY3568, you can find SDK, tutorials, tech docs and dev tools are provided, making development simpler and more convenient. Any custimzation requirements or technical support please contact us by wpd#youeetoo.com (#------\u0026gt;@) or post your quesiton on http(s):\/\/forum.youyeetoo.com\/\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2025-10-16T03:25:37+11:00","created_at":"2025-10-16T03:25:33+11:00","vendor":"WayPonDEV","type":"","tags":["electronics_selected_Oct2025"],"price":33800,"price_min":33800,"price_max":33800,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":48876739133677,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0CGXH52JJ","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"YY3568 Open-Source Developer Kit Rockchip RK3568 Soc Support Android11.0, Debian10.0 and OpenHarmony OS, 64-bit AI Mainboard for Face Recognition Prototyping (Metal Kit with WiFi 8GB RAM)","public_title":null,"options":["Default Title"],"price":33800,"weight":590,"compare_at_price":null,"inventory_management":"shopify","barcode":"1258796534","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/leoforward.com\/cdn\/shop\/files\/B0CGXH52JJ.jpg?v=1775787577","\/\/leoforward.com\/cdn\/shop\/files\/61ue95jIaEL.jpg?v=1760545536","\/\/leoforward.com\/cdn\/shop\/files\/71k7qzRZJoL.jpg?v=1760545536","\/\/leoforward.com\/cdn\/shop\/files\/71rLX2hqXoL.jpg?v=1760545536"],"featured_image":"\/\/leoforward.com\/cdn\/shop\/files\/B0CGXH52JJ.jpg?v=1775787577","options":["Title"],"media":[{"alt":null,"id":36911588049133,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/leoforward.com\/cdn\/shop\/files\/B0CGXH52JJ.jpg?v=1775787577"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/B0CGXH52JJ.jpg?v=1775787577","width":1600},{"alt":null,"id":36911588081901,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/leoforward.com\/cdn\/shop\/files\/61ue95jIaEL.jpg?v=1760545536"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/61ue95jIaEL.jpg?v=1760545536","width":1600},{"alt":null,"id":36911588114669,"position":3,"preview_image":{"aspect_ratio":1.587,"height":1178,"width":1869,"src":"\/\/leoforward.com\/cdn\/shop\/files\/71k7qzRZJoL.jpg?v=1760545536"},"aspect_ratio":1.587,"height":1178,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/71k7qzRZJoL.jpg?v=1760545536","width":1869},{"alt":null,"id":36911588147437,"position":4,"preview_image":{"aspect_ratio":0.554,"height":2560,"width":1419,"src":"\/\/leoforward.com\/cdn\/shop\/files\/71rLX2hqXoL.jpg?v=1760545536"},"aspect_ratio":0.554,"height":2560,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/71rLX2hqXoL.jpg?v=1760545536","width":1419}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eYY3568 Open-Source Developer Kit Rockchip RK3568 Soc Support Android11.0, Debian10.0 and OpenHarmony OS, 64-bit AI Mainboard for Face Recognition Prototyping (Metal Kit with WiFi 8GB RAM)\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003e-Specification- Soc: Rockchip RK3568 CPU: Quad-core 64-bit Cortex-A55, 22nm lithography process, frequency up to 2.0GHz GPU: ARM G52 2EE Supports OpenGL ES 1.1\/2.0\/3.2，OpenCL 2.0，Vulkan 1.1, Embedded high-performance 2D acceleration hardware\" NPU: 0.8Tops@INT8,integrated high-performance AI accelerator RKNN NPU Supports 8M ISP, supports HDR RAM: 2GB LPDDR4 Storage: 16GB eMMC -OS\/Software- OS Support Android11, Debian10,OpenHarmony system Power Supply: 1 x 12~19V DC Power Input Jack (5.5\/2.1 mm) -Others- Size:120mm x 88mm x 19mm Weight: 113g Operating Temperature: -10℃～60℃\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eKind Reminder: There are various variants. For shipping list, you can refer to the last description of title(content in brackets) or you can contact us by click\"WayPonDev\" if you are not sure.\u003c\/li\u003e\r\n \u003cli\u003e[Android and Linux OS Support] YY3568 is compatible with Android 11.0, debian 10.0 and OpenHarmony OS,which gives users options and flexibility when developing their projects\u003c\/li\u003e\r\n \u003cli\u003e[Customizable Hardware and Software]The core board conbined with carrier board design that help YY3568 developer kit provides users with the ability to customize hardware functions. And we can also offer cross-soc OS porting, BSP kernel trimming, as well as driver development. This allows for a tailored experience and more effective development\u003c\/li\u003e\r\n \u003cli\u003e[Easy to Use Add-ons and Accessories] WayPonDEV team develop a variety of compatible accessories including 7-inch MIPI Touch Screen, 11.6-inch eDP touch screen, cameras, 4GB LTE module and acrylic case as well as metal shell etc. This helps greatly reduce the cycle from product selection, R\u0026amp;D project establishment, small batch trial production to mass production\u003c\/li\u003e\r\n \u003cli\u003e[Fast Network Communication] - With onboard dual adaptive Gigabit Ethernet RJ45, 2.4GHz\/5GHz dual-band WiFi 5 (WiFi5, 802.11a\/b\/g\/n\/ac\/ protocol), Bluetooth 5.0, and 4G LTE expansion supported, YY3568 ensures faster-rate, larger-capacity, and lower-latency network communication\u003c\/li\u003e\r\n \u003cli\u003e[Rich Extensible Interfaces]Equipped with interfaces such as CAN, M.2 PCIE3.0, USB3.0, I2C, SPDIF, UARTx5,UART Debug,4x ADC,30 GPIO, 2x MULTI_PHY, MIPI-DSI,CSI, MIC and 12~19V DC Power Input Jack (5.5\/2.1 mm),it can be directly used in various intelligent products to facilitate the completion of products\u003c\/li\u003e\r\n \u003cli\u003e[Wiki] http(s):\/\/wiki.youyeetoo.com\/YY3568, you can find SDK, tutorials, tech docs and dev tools are provided, making development simpler and more convenient. Any custimzation requirements or technical support please contact us by wpd#youeetoo.com (#------\u0026gt;@) or post your quesiton on http(s):\/\/forum.youyeetoo.com\/\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
