{"id":9143326015725,"title":"Power Management HAT for Raspberry Pi Series Board, Onboard RTC \u0026 Buck-Boost DC Chip,Supports Charging and Power Output at The Same Time","handle":"power-management-hat-for-raspberry-pi-series-board-onboard-rtc-buck-boost-dc-chip-supports-charging-and-power-output-at-the-same-time","description":"\u003ch3\u003ePower Management HAT for Raspberry Pi Series Board, Onboard RTC \u0026amp; Buck-Boost DC Chip,Supports Charging and Power Output at The Same Time\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eFeatures Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry\r\nPi series boards Dual-core Arm Cortex M0+ processor, flexible clock running up\r\nto 133 MHz Onboard PCF8523 RTC chip, provides precise RTC information Onboard\r\nMP28167-A buck-boost DC chip for fast load transient response Onboard user-\r\ndefined button, can be used for Raspberry Pi start up, safely shutdown, or\r\nother customized function Protection circuits such as: power supply anti-\r\nreverse, counter current proof, etc. ensures stable and safe operating\r\nVoltage\/current monitoring circuit, monitors the Raspberry Pi operating\r\nvoltage and current in real time Comes with complete resources and manual\r\nPackage include 1. Power Management HAT (B) x1 2. 2x20PIN female header x1 3.\r\nUSB cable type A male port to Type C male port x1 4. Screws pack x1 Resources\r\navailable\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eDual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz\u003c\/li\u003e\r\n \u003cli\u003eOnboard PCF8523 RTC chip, provides precise RTC information\u003c\/li\u003e\r\n \u003cli\u003eOnboard MP28167-A buck-boost DC chip for fast load transient response\u003c\/li\u003e\r\n \u003cli\u003eOnboard user-defined button, can be used for Raspberry Pi start up, safely shutdown, or other customized function\u003c\/li\u003e\r\n \u003cli\u003eProtection circuits such as: power supply anti-reverse, counter current proof, etc. ensures stable and safe operating\u003c\/li\u003e\r\n \u003cli\u003eVoltage\/current monitoring circuit, monitors the Raspberry Pi operating voltage and current in real time\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2025-10-17T03:50:36+11:00","created_at":"2025-10-17T03:50:32+11:00","vendor":"Coolwell","type":"","tags":["electronics_selected_Oct2025"],"price":16500,"price_min":16500,"price_max":16500,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":48882233114861,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0BN93N5MX","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Power Management HAT for Raspberry Pi Series Board, Onboard RTC \u0026 Buck-Boost DC Chip,Supports Charging and Power Output at The Same Time","public_title":null,"options":["Default Title"],"price":16500,"weight":86,"compare_at_price":null,"inventory_management":"shopify","barcode":"734730695532","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/leoforward.com\/cdn\/shop\/files\/B0BN93N5MX.jpg?v=1775789693","\/\/leoforward.com\/cdn\/shop\/files\/612KAKOOiYL.jpg?v=1760633434","\/\/leoforward.com\/cdn\/shop\/files\/61mwUtxpf0L.jpg?v=1760633434","\/\/leoforward.com\/cdn\/shop\/files\/51b4P8hYVtL.jpg?v=1760633434","\/\/leoforward.com\/cdn\/shop\/files\/71zbaNss2pL.jpg?v=1760633434","\/\/leoforward.com\/cdn\/shop\/files\/713zCdct9xL.jpg?v=1760633434","\/\/leoforward.com\/cdn\/shop\/files\/71dh4mhp_5L.jpg?v=1760633436","\/\/leoforward.com\/cdn\/shop\/files\/71jforU2zCL.jpg?v=1760633435"],"featured_image":"\/\/leoforward.com\/cdn\/shop\/files\/B0BN93N5MX.jpg?v=1775789693","options":["Title"],"media":[{"alt":null,"id":36920100323565,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1102,"width":1102,"src":"\/\/leoforward.com\/cdn\/shop\/files\/B0BN93N5MX.jpg?v=1775789693"},"aspect_ratio":1.0,"height":1102,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/B0BN93N5MX.jpg?v=1775789693","width":1102},{"alt":null,"id":36920100356333,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1102,"width":1102,"src":"\/\/leoforward.com\/cdn\/shop\/files\/612KAKOOiYL.jpg?v=1760633434"},"aspect_ratio":1.0,"height":1102,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/612KAKOOiYL.jpg?v=1760633434","width":1102},{"alt":null,"id":36920100389101,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1102,"width":1102,"src":"\/\/leoforward.com\/cdn\/shop\/files\/61mwUtxpf0L.jpg?v=1760633434"},"aspect_ratio":1.0,"height":1102,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/61mwUtxpf0L.jpg?v=1760633434","width":1102},{"alt":null,"id":36920100421869,"position":4,"preview_image":{"aspect_ratio":1.61,"height":856,"width":1378,"src":"\/\/leoforward.com\/cdn\/shop\/files\/51b4P8hYVtL.jpg?v=1760633434"},"aspect_ratio":1.61,"height":856,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/51b4P8hYVtL.jpg?v=1760633434","width":1378},{"alt":null,"id":36920100454637,"position":5,"preview_image":{"aspect_ratio":0.284,"height":2560,"width":726,"src":"\/\/leoforward.com\/cdn\/shop\/files\/71zbaNss2pL.jpg?v=1760633434"},"aspect_ratio":0.284,"height":2560,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/71zbaNss2pL.jpg?v=1760633434","width":726},{"alt":null,"id":36920100487405,"position":6,"preview_image":{"aspect_ratio":0.246,"height":2560,"width":631,"src":"\/\/leoforward.com\/cdn\/shop\/files\/713zCdct9xL.jpg?v=1760633434"},"aspect_ratio":0.246,"height":2560,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/713zCdct9xL.jpg?v=1760633434","width":631},{"alt":null,"id":36920100520173,"position":7,"preview_image":{"aspect_ratio":0.245,"height":2560,"width":627,"src":"\/\/leoforward.com\/cdn\/shop\/files\/71dh4mhp_5L.jpg?v=1760633436"},"aspect_ratio":0.245,"height":2560,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/71dh4mhp_5L.jpg?v=1760633436","width":627},{"alt":null,"id":36920100552941,"position":8,"preview_image":{"aspect_ratio":1.333,"height":1920,"width":2560,"src":"\/\/leoforward.com\/cdn\/shop\/files\/71jforU2zCL.jpg?v=1760633435"},"aspect_ratio":1.333,"height":1920,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/71jforU2zCL.jpg?v=1760633435","width":2560}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003ePower Management HAT for Raspberry Pi Series Board, Onboard RTC \u0026amp; Buck-Boost DC Chip,Supports Charging and Power Output at The Same Time\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eFeatures Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry\r\nPi series boards Dual-core Arm Cortex M0+ processor, flexible clock running up\r\nto 133 MHz Onboard PCF8523 RTC chip, provides precise RTC information Onboard\r\nMP28167-A buck-boost DC chip for fast load transient response Onboard user-\r\ndefined button, can be used for Raspberry Pi start up, safely shutdown, or\r\nother customized function Protection circuits such as: power supply anti-\r\nreverse, counter current proof, etc. ensures stable and safe operating\r\nVoltage\/current monitoring circuit, monitors the Raspberry Pi operating\r\nvoltage and current in real time Comes with complete resources and manual\r\nPackage include 1. Power Management HAT (B) x1 2. 2x20PIN female header x1 3.\r\nUSB cable type A male port to Type C male port x1 4. Screws pack x1 Resources\r\navailable\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eDual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz\u003c\/li\u003e\r\n \u003cli\u003eOnboard PCF8523 RTC chip, provides precise RTC information\u003c\/li\u003e\r\n \u003cli\u003eOnboard MP28167-A buck-boost DC chip for fast load transient response\u003c\/li\u003e\r\n \u003cli\u003eOnboard user-defined button, can be used for Raspberry Pi start up, safely shutdown, or other customized function\u003c\/li\u003e\r\n \u003cli\u003eProtection circuits such as: power supply anti-reverse, counter current proof, etc. ensures stable and safe operating\u003c\/li\u003e\r\n \u003cli\u003eVoltage\/current monitoring circuit, monitors the Raspberry Pi operating voltage and current in real time\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
