{"id":9139088031981,"title":"ESP32-C6-DevKitC-1 N8 Development Board ESP32 C6 32-bit 8MB SPI Flash ESP32-C6-WROOM-1 Module Supports Wi-Fi BLE Zigbee3.0 Thread1.3","handle":"esp32-c6-devkitc-1-n8-development-board-esp32-c6-32-bit-8mb-spi-flash-esp32-c6-wroom-1-module-supports-wi-fi-ble-zigbee3-0-thread1-3","description":"\u003ch3\u003eESP32-C6-DevKitC-1 N8 Development Board ESP32 C6 32-bit 8MB SPI Flash ESP32-C6-WROOM-1 Module Supports Wi-Fi BLE Zigbee3.0 Thread1.3\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eFeatures: CPU and On-Chip Memory ESP32-C6 embedded, 32-bit RISC-V single-core\r\nmicroprocessor, up to 160 MHz ROM:320 KB HP SRAM: 512 KB LP SRAM: 16 KB Wi-Fi:\r\n1T1R in 2.4 GHz band Operating frequency: 2412～2484 MHz IEEE 802.11ax-\r\ncompliant Fully compatible with IEEE802.11b\/g\/n protocol Blue-tooth:\r\nBluetoothLE: Bluetooth5.3 certified Blue-tooth mesh High power mod (20dBm)\r\nSpeed:125Kbps, 500Kbps, 1Mbps, 2Mbps Advertising extensions Multiple\r\nadvertisement sets Channel selection algorithm2 LE power control Internal co-\r\nexistence mechanism between Wi-Fi and Bluetooth to share the same antenna\r\nIEEE802.15.4: Compliant with IEEE802.15.42015 protocol OQPSK PHY in 2.4 GHz\r\nband Data rate: 250Kbps Thread1.3 Zigbee3.0 Peripherals: GPIO, SPI, parallel\r\nIO interface, UART, I2C, I2S, RM (TX\/RX), pulse counter, LED PWM, USB\r\nSerial\/JTA Gcontroller, MCPWM, SDIO2.0 slave controller, GDMA, TWAI\r\ncontroller, on-chip debug functionality via JTAG, event task matrix,\r\nADC,temperature sensor,general-purpose timers, watchdog timers, etc.\r\nIntegrated Components on Module: 40 MHz crystal oscillator SPI flash\r\nApplications: Smart Home Pos machines Industrial Automation Service robot\r\nHealth Care Audio Devices Consumer Electronics Generic Low-power loT Sensor\r\nHubs Smart Agriculture Generic Low-power loT Data Loggers Package includes: 1\r\nX ESP32-C6-DevKitC-1 N8 development board\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eESP32-C6-DevKitC-1 is an entry-level development board based on ESP32-C6-WROOM-1, integrates complete Wi-Fi, Blue-tooth LE, Zig-bee, and Thread functions, supports 2.4 GHz Wi-Fi 6 (802.11 ax), Bluetooth5(LE), Zigbee3.0 and Thread1.3 (802.15.4)\u003c\/li\u003e\r\n \u003cli\u003eBuilt around ESP32-C6 series of SoCs, 32-bit RISC-V single-core microprocessor, comes with a 8 MB SPI flash, uses on-board PCB antenna\u003c\/li\u003e\r\n \u003cli\u003eMost of the I\/O pins are broken out to the pin headers on both sides for easy interfacing. Developers can either connect peripherals with jumper wires or mount ESP32-C6-DevKitC-1 on a breadboard\u003c\/li\u003e\r\n \u003cli\u003eThere are three mutually exclusive ways to provide power to the board: 1 USB Type-C to UART Port and ESP32-C6 USB Type-C Port (either one or both), default power supply (recommended) 2 5V and GND pin headers 3 3V3 and GND pin headers\u003c\/li\u003e\r\n \u003cli\u003eApplications: Smart Home, Pos machines, Industrial Automation, Service robot, Health Care Audio Devices, Consumer Electronics, Generic Low-power loT Sensor Hubs, Smart Agriculture, Generic Low-power loT Data Loggers\u003c\/li\u003e\r\n \u003cli\u003eWhat you will get: 1 X ESP32-C6-DevKitC-1 N8 development board\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2025-10-14T19:08:14+11:00","created_at":"2025-10-14T19:08:11+11:00","vendor":"DIYmall","type":"","tags":["electronics_selected_Oct2025"],"price":15300,"price_min":15300,"price_max":15300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":48869772656877,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0CFXXCDRL","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"ESP32-C6-DevKitC-1 N8 Development Board ESP32 C6 32-bit 8MB SPI Flash ESP32-C6-WROOM-1 Module Supports Wi-Fi BLE Zigbee3.0 Thread1.3","public_title":null,"options":["Default Title"],"price":15300,"weight":36,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/leoforward.com\/cdn\/shop\/files\/B0CFXXCDRL.jpg?v=1775785910","\/\/leoforward.com\/cdn\/shop\/files\/51PtOoVsw1L.jpg?v=1760429294","\/\/leoforward.com\/cdn\/shop\/files\/71bLvWCJ45L.jpg?v=1760429293","\/\/leoforward.com\/cdn\/shop\/files\/61An2fAjUQL.jpg?v=1760429293","\/\/leoforward.com\/cdn\/shop\/files\/71GCLAl0NFL.jpg?v=1760429294","\/\/leoforward.com\/cdn\/shop\/files\/515xwbIaa9L.jpg?v=1760429293"],"featured_image":"\/\/leoforward.com\/cdn\/shop\/files\/B0CFXXCDRL.jpg?v=1775785910","options":["Title"],"media":[{"alt":null,"id":36900149199085,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/leoforward.com\/cdn\/shop\/files\/B0CFXXCDRL.jpg?v=1775785910"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/B0CFXXCDRL.jpg?v=1775785910","width":1000},{"alt":null,"id":36900149231853,"position":2,"preview_image":{"aspect_ratio":0.967,"height":1000,"width":967,"src":"\/\/leoforward.com\/cdn\/shop\/files\/51PtOoVsw1L.jpg?v=1760429294"},"aspect_ratio":0.967,"height":1000,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/51PtOoVsw1L.jpg?v=1760429294","width":967},{"alt":null,"id":36900149264621,"position":3,"preview_image":{"aspect_ratio":0.707,"height":1416,"width":1001,"src":"\/\/leoforward.com\/cdn\/shop\/files\/71bLvWCJ45L.jpg?v=1760429293"},"aspect_ratio":0.707,"height":1416,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/71bLvWCJ45L.jpg?v=1760429293","width":1001},{"alt":null,"id":36900149297389,"position":4,"preview_image":{"aspect_ratio":1.278,"height":783,"width":1001,"src":"\/\/leoforward.com\/cdn\/shop\/files\/61An2fAjUQL.jpg?v=1760429293"},"aspect_ratio":1.278,"height":783,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/61An2fAjUQL.jpg?v=1760429293","width":1001},{"alt":null,"id":36900149330157,"position":5,"preview_image":{"aspect_ratio":0.707,"height":2339,"width":1653,"src":"\/\/leoforward.com\/cdn\/shop\/files\/71GCLAl0NFL.jpg?v=1760429294"},"aspect_ratio":0.707,"height":2339,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/71GCLAl0NFL.jpg?v=1760429294","width":1653},{"alt":null,"id":36900149362925,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/leoforward.com\/cdn\/shop\/files\/515xwbIaa9L.jpg?v=1760429293"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/515xwbIaa9L.jpg?v=1760429293","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eESP32-C6-DevKitC-1 N8 Development Board ESP32 C6 32-bit 8MB SPI Flash ESP32-C6-WROOM-1 Module Supports Wi-Fi BLE Zigbee3.0 Thread1.3\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eFeatures: CPU and On-Chip Memory ESP32-C6 embedded, 32-bit RISC-V single-core\r\nmicroprocessor, up to 160 MHz ROM:320 KB HP SRAM: 512 KB LP SRAM: 16 KB Wi-Fi:\r\n1T1R in 2.4 GHz band Operating frequency: 2412～2484 MHz IEEE 802.11ax-\r\ncompliant Fully compatible with IEEE802.11b\/g\/n protocol Blue-tooth:\r\nBluetoothLE: Bluetooth5.3 certified Blue-tooth mesh High power mod (20dBm)\r\nSpeed:125Kbps, 500Kbps, 1Mbps, 2Mbps Advertising extensions Multiple\r\nadvertisement sets Channel selection algorithm2 LE power control Internal co-\r\nexistence mechanism between Wi-Fi and Bluetooth to share the same antenna\r\nIEEE802.15.4: Compliant with IEEE802.15.42015 protocol OQPSK PHY in 2.4 GHz\r\nband Data rate: 250Kbps Thread1.3 Zigbee3.0 Peripherals: GPIO, SPI, parallel\r\nIO interface, UART, I2C, I2S, RM (TX\/RX), pulse counter, LED PWM, USB\r\nSerial\/JTA Gcontroller, MCPWM, SDIO2.0 slave controller, GDMA, TWAI\r\ncontroller, on-chip debug functionality via JTAG, event task matrix,\r\nADC,temperature sensor,general-purpose timers, watchdog timers, etc.\r\nIntegrated Components on Module: 40 MHz crystal oscillator SPI flash\r\nApplications: Smart Home Pos machines Industrial Automation Service robot\r\nHealth Care Audio Devices Consumer Electronics Generic Low-power loT Sensor\r\nHubs Smart Agriculture Generic Low-power loT Data Loggers Package includes: 1\r\nX ESP32-C6-DevKitC-1 N8 development board\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eESP32-C6-DevKitC-1 is an entry-level development board based on ESP32-C6-WROOM-1, integrates complete Wi-Fi, Blue-tooth LE, Zig-bee, and Thread functions, supports 2.4 GHz Wi-Fi 6 (802.11 ax), Bluetooth5(LE), Zigbee3.0 and Thread1.3 (802.15.4)\u003c\/li\u003e\r\n \u003cli\u003eBuilt around ESP32-C6 series of SoCs, 32-bit RISC-V single-core microprocessor, comes with a 8 MB SPI flash, uses on-board PCB antenna\u003c\/li\u003e\r\n \u003cli\u003eMost of the I\/O pins are broken out to the pin headers on both sides for easy interfacing. Developers can either connect peripherals with jumper wires or mount ESP32-C6-DevKitC-1 on a breadboard\u003c\/li\u003e\r\n \u003cli\u003eThere are three mutually exclusive ways to provide power to the board: 1 USB Type-C to UART Port and ESP32-C6 USB Type-C Port (either one or both), default power supply (recommended) 2 5V and GND pin headers 3 3V3 and GND pin headers\u003c\/li\u003e\r\n \u003cli\u003eApplications: Smart Home, Pos machines, Industrial Automation, Service robot, Health Care Audio Devices, Consumer Electronics, Generic Low-power loT Sensor Hubs, Smart Agriculture, Generic Low-power loT Data Loggers\u003c\/li\u003e\r\n \u003cli\u003eWhat you will get: 1 X ESP32-C6-DevKitC-1 N8 development board\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
