{"id":9140787118317,"title":"10\/100Mbps Fast Ethernet Media Converter, Single-Mode SC Fiber, up to 20km, 10\/100Base-TX to 100Base-FX 2 Port | 1x Fiber slot","handle":"10-100mbps-fast-ethernet-media-converter-single-mode-sc-fiber-up-to-20km-10-100base-tx-to-100base-fx-2-port-1x-fiber-slot","description":"\u003ch3\u003e10\/100Mbps Fast Ethernet Media Converter, Single-Mode SC Fiber, up to 20km, 10\/100Base-TX to 100Base-FX\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eFeatures: 128 K's data buffer RAM Support for low-delay time pure data\r\ntransmission and full\/half-duplex flow control. Built-in watch-dog timer to\r\nmonitor any error in internal data exchange Interface: 1 x Ethernet port\r\n(RJ45) 10\/100Base-Tx 1 x Optical port (Dual SC) 100Base-Fx Optical Port:\r\n1310nm Single mode Transfer Distance: up to 20km Connectors: Dual SC connector\r\nFiber core: 8.3um, 8.7um, 9um and 10um on single mode fiber Optical Power\r\n(dBm): -15~ -3 Receiving Sensitivity (dBm): ≤-32 Ethernet Port: In accordance\r\nwith Ethernet standards IEEE802.3 10Base-T, IEEE802.3u 100Base-T and 100Base-\r\nFX Available speed: auto-detective 10\/100Mbps Full-Duplex and Half-Duplex\r\nauto-negotiation Connectors: RJ-45 connector; MDI\/MDI-X connection auto-\r\nsensing LED Indicators: FX, TX, Link\/Act(Left\/Right), FDX, PWR FX: Light on\r\nwhen fiber speed is 100Mbps, while “OFF” means the rate is 10 Mbps TX: Light\r\non when TP speed is 100Mbps, while “OFF” means the rate is 10 Mbps. Link\/ACT:\r\nLeft side is indicate for fiber port link\/act and right side for TP,light\r\nflashing when data transmitting and receiving FDX: Light on when TP full-\r\nduplex mode is active,light off when TP half-duplex mode is active PWR: Light\r\non when DC power on, else light off Specifications: Output voltage: AC 220V or\r\nDC5V 1A Power dissipation: ≤1 watts Housing: Metal enclosure Volume:\r\n94x70x26mm (LxWxH) Operating Temperature: 0°C to 60°C Storage Temperature:\r\n-20°C to 70°C Humidity: 5% to 90% RH Checklist: Before you installing the\r\nConverter,verify that the package contains the following: 1.The Ethernet Media\r\nConverter 2.AC\/DC Power Adapter 3.User’s Manual\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eOptical Port: 100Mbps, Dual SC singlemode fiber, support 100M Ethernet.\u003c\/li\u003e\r\n \u003cli\u003eRJ45 Port: CAT5E\/CAT6 10M\/100M, Full Duplex or Half Duplex; Supports MDI\/MDI-X auto crossover.\u003c\/li\u003e\r\n \u003cli\u003eComplies with IEEE IEEE 802.3\/802.3u\/802.3af.\u003c\/li\u003e\r\n \u003cli\u003eStatus LED's for TX, FX LINK\/ACT, POWER, FDX to easily monitor network status.\u003c\/li\u003e\r\n \u003cli\u003eSupports wide temperature range from 0C to 60C.\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2025-10-16T03:10:13+11:00","created_at":"2025-10-16T03:10:08+11:00","vendor":"10Gtek","type":"","tags":["electronics_selected_Oct2025"],"price":16000,"price_min":16000,"price_max":16000,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":48876654133485,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B071D5DN37","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"10\/100Mbps Fast Ethernet Media Converter, Single-Mode SC Fiber, up to 20km, 10\/100Base-TX to 100Base-FX 2 Port | 1x Fiber slot","public_title":null,"options":["Default Title"],"price":16000,"weight":204,"compare_at_price":null,"inventory_management":"shopify","barcode":"A7S1-33-1FX1TX-H-SC20","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/leoforward.com\/cdn\/shop\/files\/B071D5DN37.jpg?v=1775787316","\/\/leoforward.com\/cdn\/shop\/files\/41v633W3J8L.jpg?v=1760544611","\/\/leoforward.com\/cdn\/shop\/files\/61Tu9lCj5dL.jpg?v=1760544612","\/\/leoforward.com\/cdn\/shop\/files\/615iiqYc7RL.jpg?v=1760544612","\/\/leoforward.com\/cdn\/shop\/files\/51-VGYFiM_L.jpg?v=1760544611"],"featured_image":"\/\/leoforward.com\/cdn\/shop\/files\/B071D5DN37.jpg?v=1775787316","options":["Title"],"media":[{"alt":null,"id":36911430500589,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/leoforward.com\/cdn\/shop\/files\/B071D5DN37.jpg?v=1775787316"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/B071D5DN37.jpg?v=1775787316","width":1600},{"alt":null,"id":36911430533357,"position":2,"preview_image":{"aspect_ratio":1.078,"height":464,"width":500,"src":"\/\/leoforward.com\/cdn\/shop\/files\/41v633W3J8L.jpg?v=1760544611"},"aspect_ratio":1.078,"height":464,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/41v633W3J8L.jpg?v=1760544611","width":500},{"alt":null,"id":36911430566125,"position":3,"preview_image":{"aspect_ratio":1.028,"height":908,"width":933,"src":"\/\/leoforward.com\/cdn\/shop\/files\/61Tu9lCj5dL.jpg?v=1760544612"},"aspect_ratio":1.028,"height":908,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/61Tu9lCj5dL.jpg?v=1760544612","width":933},{"alt":null,"id":36911430598893,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1008,"width":1008,"src":"\/\/leoforward.com\/cdn\/shop\/files\/615iiqYc7RL.jpg?v=1760544612"},"aspect_ratio":1.0,"height":1008,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/615iiqYc7RL.jpg?v=1760544612","width":1008},{"alt":null,"id":36911430631661,"position":5,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/leoforward.com\/cdn\/shop\/files\/51-VGYFiM_L.jpg?v=1760544611"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/leoforward.com\/cdn\/shop\/files\/51-VGYFiM_L.jpg?v=1760544611","width":800}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003e10\/100Mbps Fast Ethernet Media Converter, Single-Mode SC Fiber, up to 20km, 10\/100Base-TX to 100Base-FX\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eFeatures: 128 K's data buffer RAM Support for low-delay time pure data\r\ntransmission and full\/half-duplex flow control. Built-in watch-dog timer to\r\nmonitor any error in internal data exchange Interface: 1 x Ethernet port\r\n(RJ45) 10\/100Base-Tx 1 x Optical port (Dual SC) 100Base-Fx Optical Port:\r\n1310nm Single mode Transfer Distance: up to 20km Connectors: Dual SC connector\r\nFiber core: 8.3um, 8.7um, 9um and 10um on single mode fiber Optical Power\r\n(dBm): -15~ -3 Receiving Sensitivity (dBm): ≤-32 Ethernet Port: In accordance\r\nwith Ethernet standards IEEE802.3 10Base-T, IEEE802.3u 100Base-T and 100Base-\r\nFX Available speed: auto-detective 10\/100Mbps Full-Duplex and Half-Duplex\r\nauto-negotiation Connectors: RJ-45 connector; MDI\/MDI-X connection auto-\r\nsensing LED Indicators: FX, TX, Link\/Act(Left\/Right), FDX, PWR FX: Light on\r\nwhen fiber speed is 100Mbps, while “OFF” means the rate is 10 Mbps TX: Light\r\non when TP speed is 100Mbps, while “OFF” means the rate is 10 Mbps. Link\/ACT:\r\nLeft side is indicate for fiber port link\/act and right side for TP,light\r\nflashing when data transmitting and receiving FDX: Light on when TP full-\r\nduplex mode is active,light off when TP half-duplex mode is active PWR: Light\r\non when DC power on, else light off Specifications: Output voltage: AC 220V or\r\nDC5V 1A Power dissipation: ≤1 watts Housing: Metal enclosure Volume:\r\n94x70x26mm (LxWxH) Operating Temperature: 0°C to 60°C Storage Temperature:\r\n-20°C to 70°C Humidity: 5% to 90% RH Checklist: Before you installing the\r\nConverter,verify that the package contains the following: 1.The Ethernet Media\r\nConverter 2.AC\/DC Power Adapter 3.User’s Manual\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eOptical Port: 100Mbps, Dual SC singlemode fiber, support 100M Ethernet.\u003c\/li\u003e\r\n \u003cli\u003eRJ45 Port: CAT5E\/CAT6 10M\/100M, Full Duplex or Half Duplex; Supports MDI\/MDI-X auto crossover.\u003c\/li\u003e\r\n \u003cli\u003eComplies with IEEE IEEE 802.3\/802.3u\/802.3af.\u003c\/li\u003e\r\n \u003cli\u003eStatus LED's for TX, FX LINK\/ACT, POWER, FDX to easily monitor network status.\u003c\/li\u003e\r\n \u003cli\u003eSupports wide temperature range from 0C to 60C.\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
